Continuous Band Sealing Machine with Adjustable Sealing Head

SV-20M vertical band sealing machine features a sealing head that allows it to adjust its angle in a 0-45 degrees range. This largely improves operating visibility as well as convenience. It is one of our best selling machines. We adopt an electronic temperature controller and a special cooling design. The seal is stable and neat even after long operating visibility. The guide strip on the conveyor belt is designed to prevent the conveyor belt from deviating. The robust structure for conveyance can convey heavy packages.  It can be installed on a production line for continuous operation.


Electric specifications:

  • Power supply AC 1Phase 110 or 220V 50/60HZ
  • Sealing width 10mm (5/15/20mm available)
  • Conveyor width 200mm (can be customized)
  • Sealing speed 5-12m/min (variable speed)
  • Temperature range 0-399 degrees Celsius
  • Conveyor Speed 0-12M/min (variable speed)
  • Conveyor loading weight 15kg
  • Bag thickness Up to 0.7mm
  • Bag length range 60-800mm
  • Operation Direction Left to Right (standard)
  • Machine Weight 136kg
  • Machine Dimensions 1530x750x1560mm


Standard Features:

  • Made in Taiwan
  • Feeding and sealing large plastic bags.
  • Applications: Liquids, cleaning products, food seasoning
  • Bag material: PE, PP, Aluminum foil bag or heat sealable materials.



  • Stainless steel body (S)
  • Pre-conveyor roller platform (U)
  • Dry Ink coder (I)
  • Ribbon coder (R)
  • Counter (C)
  • Conveyor width 300/400 mm
  • Conveyor size 2600 mm x 300 mm
  • Gas Flush System (G)
